Industrial-Grade Stainless Steel Belt Buckle Ratchet | Ultimate Corrosion Resistance for 5-Ton Loads

Basic Properties
Place of Origin: China
Brand Name: Anfeng
Certification: CE, GS, ISO9001
Model Number: RA50-5T
Trading Properties
Minimum Order Quantity: 500 pcs
Price: Call or Email for quote
Payment Terms: T/T, L/C
Supply Ability: 10,000 pcs per month
Product Summary
Product Description: Meta Description: Unbeatable corrosion resistance for maritime & agricultural use. Our heavy-duty lashing belt features a full 304 Stainless Steel ratchet buckle, 50mm PE polyester webbing, and a 5-ton capacity for NZ, EU & US professionals. (Introduction) For industries where rust is the enemy—from the salt-laden ports of New Zealand to the chemical-rich environments of European agriculture and North American road maintenance—standard ratchet straps fail

Product Details

Material: Polyester
Weather Resistance: Yes
Abrasion Resistance: Yes
Rust Resistance: Yes
Safety Factor: 3:1
Product Category: Ratchet Tie Down Straps
Width: 2 Inches
UV Resistance: Yes
Product Description

Product Description:



Meta Description: Unbeatable corrosion resistance for maritime & agricultural use. Our heavy-duty lashing belt features a full 304 Stainless Steel ratchet buckle, 50mm PE polyester webbing, and a 5-ton capacity for NZ, EU & US professionals.

(Introduction)
For industries where rust is the enemy—from the salt-laden ports of New Zealand to the chemical-rich environments of European agriculture and North American road maintenance—standard ratchet straps fail prematurely. Introducing the Stainless Steel Belt Buckle Heavy-Duty Webbing Ratchet, a lashing solution engineered from the ground up to conquer corrosion. With a fully stainless steel ratchet mechanism and premium PE webbing, this belt delivers unwavering 5-ton security and an exceptionally long lifespan, redefining value in demanding applications.

(Key Features & Differentiated Advantages)

1. 100% 304 Grade Stainless Steel Ratchet Buckle – The Rust-Free Core
The heart of this lashing belt is its fully stainless steel ratchet mechanism, crafted from marine-grade 304 stainless steel. Unlike coated or plated ratchets that chip and corrode, our buckle is inherently resistant to rust, saltwater spray, chemicals, and harsh cleaning agents. This is a critical advantage for the fishing industry, fertiliser transport, food-grade logistics, and winter road operations where de-icing salts are used.

2. "No-Jam" Sealed Pawl Mechanism
We've engineered the internal mechanism to be as resilient as the material. The ratchet features a sealed pawl and spring system protected from grit, dirt, and debris—a common cause of failure in dusty agricultural or construction environments. This "No-Jam" design ensures smooth, reliable operation and consistent tensioning, load after load, reducing downtime and frustration on the job site.

3. PE Polyester Webbing with Anti-Abrasion Sleeve
The heavy-duty 50mm webbing is made from Polyethylene (PE) coated polyester, offering superior resistance to UV degradation and moisture. As a key differentiator, the webbing includes a reinforced, double-stitched abrasion sleeve at the buckle contact point. This high-wear area is fortified to prevent fraying and tearing, addressing the most common point of strap failure and significantly extending the product's service life.

4. Ergonomic Leverage & Safety Lock
Despite its heavy-duty construction, the ratchet is designed for user efficiency. The handle incorporates an optimized pivot point and extended length, providing maximum mechanical advantage to achieve high tension with minimal effort. A positive safety lock ensures the handle remains securely closed during transit, preventing accidental release and enhancing overall transport safety.

(Product Parameters / Specifications Table)



Parameter Specification
Working Load Limit (WLL) 5,000 kg (11,000 lbs)
Break Strength 15,000 kg (33,000 lbs)
Ratchet Buckle Material 100% 304 Grade Stainless Steel
Webbing Material PE-Coated High-Tenacity Polyester
Webbing Width 50 mm (2 inches)
Webbing Length 5 meters (Standard. Other lengths available)
Color High-Visibility Orange or Navy Blue
Key Feature Sealed "No-Jam" Mechanism & Anti-Abrasion Sleeve
Hook Type 304 Stainless Steel S-Hooks (Option: Auto-Lock)
Standards Complies with EN 12195-2; DNV-GL Certified for Marine Use

(Why Choose Our Stainless Steel Buckle Straps?)

  • Total Cost of Ownership Champion: The initial investment is offset by a dramatically longer lifespan than galvanized straps, eliminating frequent replacements and saving money.

  • Built for Harsh Environments: Specifically designed to perform flawlessly in the most corrosive conditions found in New Zealand, European, and North American industries.

  • Enhanced Safety & Reliability: The sealed mechanism and anti-abrasion features provide peace of mind, knowing your cargo is secured by the most reliable equipment.

  • Uncompromised Performance: You don't sacrifice strength for corrosion resistance. This strap delivers the full 5-ton Working Load Limit with the durability to match.

(Conclusion)
Stop replacing rusted and seized ratchets. Invest in the permanent solution for heavy-duty, corrosive-environment lashing. Choose the Stainless Steel Belt Buckle Ratchet for security that stands the test of time and elements. Add to Cart today!
