GB/T 16762 Four Leg Wire Rope Sling , 32mm Galvanized Cable Sling With Loops
Basic Properties
Place of Origin:
China
Brand Name:
Anfeng / AF
Certification:
CE, ISO 9001
Model Number:
CSFFS32
Trading Properties
Minimum Order Quantity:
500 pcs
Price:
Call or Email for quote
Payment Terms:
T/T, L/C
Supply Ability:
10,000 pcs per month
Product Summary
32mm Four-leg steel wire rope slings, fibre core, swaged wire rope with Flemish Eye Sleeve and Thimble, equipped with Master Link Four-leg wire rope sling assembly, fibre core, Soft Eye and Eye Sling Description All our four-leg steel wire rope sling assemblies are produced according to our DNV Quality Management Approved System. The sling assemblies with fibre core feature 6 x 37 +FC construction, with 1670MPa in tensile strength. Each leg is a single soft eye wire rope
Product Details
Highlight:
32mm Four Leg Wire Rope Sling
,ISO 9001 Four Leg Wire Rope Sling
,GB/T 16762 Galvanized Cable Sling With Loops
Brand Name:
Anfeng / AF
Standard:
EN 13414-1: 2003, EN 13411-3: 2004, GB/T 16762-2009, GB/T 14737-2009
Material:
Galvanized Steel Wire Rope With Fibre Core
Strength:
1670 MPa
Length:
Customized
Wire Rope End Fittings:
Flemish Eye Sleeve And Thimble
Key Word:
Four-leg Wire Rope Sling, Wire Rope With Flemish Eye Sleeve And Thimble, Fibre Core, Sling Assembly
OEM Or ODM Services:
Yes, Upon Request
Place Of Origin:
Shanghai Or Guangzhou, China
Packing:
Carton + Pallet, Wooden Box, Or Custom
Equipped With:
Standard Shackle Or Hook And Master Links
Product Description
32mm Four-leg steel wire rope slings, fibre core, swaged wire rope with Flemish Eye Sleeve and Thimble, equipped with Master Link
Four-leg wire rope sling assembly, fibre core, Soft Eye and Eye Sling
Description
All our four-leg steel wire rope sling assemblies are produced according to our DNV Quality Management Approved System. The sling assemblies with fibre core feature 6 x 37 +FC construction, with 1670MPa in tensile strength.
Each leg is a single soft eye wire rope sling, which is mechanically pressed and secured with a ferrule, to create an eye-shaped loop, making it to be utilised for a range of applications. This soft loop has been left natural. A ‘hard-eye’ would be a loop that’s supported along the inside of the loop using a metal thimble.
Having thimbles at each end means that this product can be used for a range of applications. For example, it could be used as a balustrade with each end looping over a hook or a shackle.
Specification
Note:
1. Reference standard: EN 13411-3: 2003, EN 13411-3: 2004, GB/T 16762-2009, GB/T 14737-2009.
2. Surface treatment of wire ropes can be galvanized and grease free, galvanized with grease and uncoated with grease.
3. The wire rope structure, tensile strength and working load limited could be customized according to customer's request.
4. Safety factor of the rigging is 5:1.
5. Safety factor of the Master Link and Hook is 4:1.
6. Safety factor of the shackle is 6:1.
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
About Anfeng Lifting & Rigging
Based in Shanghai Free Trade Zone, Shanghai Anfeng Lifting & Rigging Ltd. is an experienced technical and sales company specialized in supplying webbing slings, round slings, wire rope and slings, chains, rigging accessories and more.
Anfeng supplies steel wire ropes, wire rope slings, lifting chains and accessories, webbing slings, round slings, fall protection harness, typhoon resistant series products, lashing, offshore mooring lines, chain hoists, lever hoists, electric hoists, shackles up to 1500t, and lifting points.
We have earned a reputation globally as a provider of high quality products, supported by our trained staff and high standard of QA/QC procedure and inspections. Our technical staffs make sure the products meet all safety and manufacturing requirements. Upon request, Anfeng provides customers with DNV-GL, CCS, ABS and other third-party inspection certificates.
