EN1492-1 3T Flat Webbing Sling for high capacity lifting / pulling

EN1492-1 3T Flat Webbing Sling for high capacity lifting / pulling

Product Details:

Place of Origin: China
Brand Name: RLB-LIFT
Certification: CE/GS/ISO
Model Number: FWS

Payment & Shipping Terms:

Minimum Order Quantity: 300pcs
Price: Negotiation
Packaging Details: Packed in carton firstly,and then reinforced with pallet for outer packing
Delivery Time: 30 working days after received your payment
Payment Terms: L/C, T/T
Supply Ability: 4*40FT container per month
Contact Now
Detailed Product Description
Product Name: Polyester Webbing Sling Lifting Eye Type: Flat Eye
Shape: Flat Standard: CE/GS/ISO
Application: Lifting Safety Factor: 7:1
Ply: Single Or Multi-ply Length: Custom
Color: Yellow

EN1492-1 3T polyester webbing lifting sling , Safety Factor: 7:1

Product Description

About the webbing sling:



Polyester flat woven webbing sling is a continue loop made from 100% polyester yarn, encased in a tubular sleeve of polyester fabric. Polyester flat woven webbing sling is widely used even when awkwardly shaped or fragile loads are being lifted.The sleeve is so constructed that it can protect and consolidate the internal rows of yarn filament and keep them in a parallel formation at all times.It’s featured as soft and light for easy rigging and conforms to the shape of load. To the cost, it’s an effective choice in high capacity lifting or pulling application.

1. 100% high tenacity polyester
2. Single ply or double ply

3. Safety factor available: 5:1, 6:1, 7:1
4. Length available:1meter to 100 meter

5. Working load limit:1-50T

6. Width:30-300mm, thickness:3.5-40mm
7. Standard:According to EN 1492-1, with certificate of conformity
8. Certificate:
CE, GS

9. Indication of working load limits (WLL): by color, number of stripes and printing
on sling and label


Advantage:


1. The product can be divided into single layer and multi-layer, and can sew in many ways.

2. The size can follow the customer's requirements.

3. Wide bearing surface, which can reduce the pressure of surface load.

4. Smooth surface, which won't hurt the lifted objects.

5. High strength-to-weight ratio.

6. It can add anti-wear protective sleeve&anti-cut protective cover.

7. It has unique label, and use international standard colors to distinguish the bearing capacity.

8. Easy to carry and soft in texture.

9. The product has experienced PU surface hardening treatment, which enhance the wear resistance.

10. Comply with European standard:EN1492-1:2000.




Specifications:

S.F

6:01

7:01

8:01

WLL

Stock No

Width

M.B.S

Stock No

Width
(mm)

M.B.S

Stock No

Width
 (mm)

M.B.S

(kg)

(mm)

(ton)

(ton)

(ton)

1000

RLB6010

25/35

6

RLB7010

30/40

7

RLB8010

50

8

2000

RLB6020

50

12

RLB7020

60

14

RLB8020

65

16

3000

RLB6030

75

18

RLB7030

90

21

RLB8030

95

24

4000

RLB6040

100

24

RLB040

120

28

RLB8040

120

32

5000

RLB6050

125

30

RLB7050

150

35

RLB8050

150

40

6000

RLB6060

150

36

RLB7060

180

42

RLB8060

180

48

8000

RLB6080

200

48

RLB7080

240

56

RLB8080

240

64

10000

RLB6100

250

60

RLB7100

300

70

RLB8100

300

80

12000

RLB6120

300

72

RLB7120

300

84

/

/

/

MEMO

JB/T8521.1

EN1492.1

AS1353





Manufacturer standard:

1. European standard:EN1492-1
2. Australian standard:AS1353
3. American standard: ASME B30.9-2006
4. Sling belt: WSTDA-WB-1


Application:

1. Steel pipe, Steel wire, Steel plate
2. Various machines and parts
3. Cement products, glass products, rubber products, wooden products, plastic products, paper products
4. Pipe laying, plumbing
5. Tree planting, Stone handling, construction and public works


Picture Show:
EN1492-1 3T Flat Webbing Sling for high capacity lifting / pulling



 Cautious



- Do not exceed working load limit

- Prevent shock-loading.

- Where selecting a sling it is very important to consider the angles at which the sling will be used.

- Slings are subject to cutting when lifting items with sharp edges. In this case always use wear sleeves.

- Do not use a damaged sling.

- Never make knots in a sling.

- Never drag a sling from underneath a load that is resting on it.

- Chemical active environments can affect the strength of slings.

- Inspect slings weekly or more frequently depending on sling use.

- Always store slings in a cool dry and dark place when they are not in use for prolonged periods.

- Always read and understand the operating instruction before use.
